Snake ⁄⁄ S2

The Snake has been designed specifically for sports turf and golf courses. We’ve seamlessly combined our world-class cut quality and articulation capabilities, and believe we’ve created the best sports turf rotary mower in the world.

Snake Series 2 – Building on Greatness.

The Trimax Snake is an accumulation of over 35 years of innovation, engineering, and customer insight. Today the Trimax Snake can be found on some of the world’s most prestigious golf courses.

Suitable for compact tractors the Snake has been designed specifically for sports turf and golf courses. We’ve seamlessly combined our world-class cut quality and added articulation capabilities never seen before on a Trimax mower.

Studied by the Sports Turf Institute of New Zealand, the Trimax Snake cutting system produces a cut quality with a similar appearance to that of a cylinder mower, but with the added versatility and reliability of our famous rotary design.

The Snake Series 2 features improvements such as the Trimax LocTEK Roller Retention System reduced maintenance and is now also available in both 3.2m and 4m cut widths. Trimax Snake owners also benefit from an industry-leading 3-year warranty. Built for agility, and incredibly robust, the Trimax Snake S2 won’t fail to impress.

Find out for yourself and book a free demonstration of the Snake S2 today.

Has dedicated machinery become too expensive?
Time to change your thinking?

These courses purchased a Trimax Snake and a tractor for the same price, or less, than a self-contained unit. Hear what they have to say about the results.
Learn More

Trimax Golf Banner

SNAKE⁄⁄ S2 Features.

The below features come as standard on all Snake S2 mowers:

EASY HEIGHT ADJUSTMENT

Clearly displayed stainless steel height indicators allow for easy adjustment of cut heights.

ARTICULATION ABILITY

With three articulating decks, the Snake has the ability to follow contours with minimal scalping.

LOCTEK ROLLER BEARING RETENTION SYSTEM

A stubless roller retention system for vastly improved alignment, bearing life, and replacement ease.

3-YEAR WARRANTY

We build mowers that last and they’re supported with a 3-year industry-leading warranty.

ZERO-TURN

Allows continuous cutting while turning sharply for maximum productivity.

LAZERBLADEZ

Achieves a superior cut and finish and is more cost-efficient than cylinder reels or solid blade beams.

FULL-WIDTH ROLLERS

Full-width front and rear rollers follow contours and provide excellent anti-scalp protection.

LOW MAINTENANCE

Features maintenance-free pivot bushes and SteadFast Sealed Spindles which do not require greasing.

AUTOMATIC BELT TENSIONERS

Eliminates the need for belt adjustments and improves drive to the spindles and blades.

IN-CAB UNLOCK SYSTEM

Unlock the mower side decks’ transport lock from the convenience of the tractor seat using a release rope.

QUIKLIFT

Enables mower decks to be raised without disengaging the PTO to traverse driveways, paths, and pavements.

SNAKE⁄⁄ S2 Options.

Anti-Bounce Skids Red

NEXABLADES

Scientifically designed for high-end turf giving a superior cut and spread when it matters most.

Electric Unlock

ELECTRIC UNLOCK

Replaces the standard in-cab transport lock release rope with an electric actuator. This is operated by a push-button remote.

Mudguards, lights and chains

MUDGUARDS, LIGHTS AND CHAINS

Add LED tail light clusters, safety chains, and transport wheel mudguards for road transportation.

Roller Scrapers

ROLLER SCRAPERS

Trimax Helical Scrapers operate with reduced tension but apply a constant pressure across the roller to assist with the cleaning of debris.

Anti-Bounce Skids Red

ANTI-BOUNCE SKIDS

Ideal for high speed mowing, Anti-Bounce Skids reduce the ‘scalping’ effect when mowing on uneven turf. Helps to ease the mower over humps between the front and rear rollers. (Currently unavailable on the ProCut 210 model).

Road Rated Tyre

ROAD RATED TYRE

Add a road-rated tyre for the ability to tow at speeds greater than 40 kph on the road.

MLS (Multi-Lift System)

MULTI-LIFT SYSTEM

The MultiLIFT System (MLS) is a combination of QuikLIFT and IndividualLIFT with the additional benefit of BiLIFT (rear deck-only mowing) for narrow gateways and driveways. Fitted with Drive Protect and timed blade spin-down for machinery protection and bystander safety.

Trimax Connect

TRIMAX CONNECT

A free app available for Trimax Multi-Lift System customers. Allows bluetooth mower connection to track mow hours, manage key service activity or control MLS functionality.

SPECIFICATIONS.

SNAKE/S2 320
SNAKE/S2 400
Cutting Width 3234 mm (127″) Cut Height Range 10 – 100 mm (⅜” – 4”)
Overall Width 3372 mm (133″) Approx. Weight 1280 kg
Overall Length 3500 mm (138”) Minimum PTO Output 35 hp
Transport Length 3160 mm (125″) Recommended Tractor HP 50 – 60 hp
Transport Height 1860 mm (73″) No. Of Blade Spindles 9
Transport Width 2100 mm (82 1/2") Workrate (6 kph) 1.94 hectares/hr
Cutting Width 3985 mm (157″) Cut Height Range 10 – 100 mm (⅜” – 4”)
Overall Width 4110 mm (162″) Approx. Weight 1580 kg
Overall Length 3500 mm (138”) Minimum PTO Output 45 hp
Transport Length 3160 mm (125″) Recommended Tractor HP 60 – 70 hp
Transport Height 2232 mm (88″) No. of Blade Spindles 11
Transport Width 2140 mm (84 1/4") Workrate (6 kph) 2.39 hectares/hr
